SICK EtherCAT microScan3 User Manual

DANGER
H
azard due to lack of effectiveness of the protective device
If there is a retroreflector in the protective field level (distance of the retroreflector from
protective field ≤6m), it may not be possible detect people and parts of the body that
are to be protected, or it may not be possible to detect them on time.
►
Avoid retroreflectors in the protective field level if possible.
►
With retroreflectors at the protective field level: Increase overrun of the protective
field over the opening to be protected by supplement Z
R
= 350mm.
DANGER
H
azard due to lack of effectiveness of the protective device
Devices with max. protective field range of 9m: Strongly reflective surfaces (e.g. shiny
metal, tile) with a distance from the protective field ≤6m can behave similarly to a
retroreflector if the laser beam hits the surface vertically. If the protective field is larger
than50% of the effective protective field range in the direction of the laser beam which
is hitting the surface vertically, it is possible that persons and parts of the body that are
to be protected will not be detected or not be detected on time.
►
Avoid strongly reflective surfaces in the protective field level if possible.
►
With strongly reflective surfaces in the protective field level: Increase overrun of
the protective field over the opening to be protected by supplement Z
R
= 350mm.
4.3.8.1 Protective field
Overview
T
he protective field must be designed so that it detects a person at a minimum
distance from the hazardous point. This distance is required to prevent a person or
part of their body from reaching the hazardous area before the end of the machine’s
dangerous state.
In access protection, the minimum distance typically defines the position at which the
safety laser scanner is mounted.
The protective field must cover a minimum area so that the safety laser scanner
reliably detects a moving person:
•
The lower edge of the protective field must not be more than 300mm above the
floor/ground according to ISO13855.
•
Resolution <150mm: The top edge of the protective field must be at least
900mm above the floor/ground according to ISO13855.
•
Resolution 150mm: The top edge of the protective field must be at least
1,100mm above the floor/ground.
•
Resolution 200mm: The top edge of the protective field must be at least
1,400mm above the floor/ground.
•
Devices with a max. protective field range of 9m: The top edge of the protective
field must be at least 1,400mm above the floor/ground.
PROJECT PLANNING 4
8025220/1L9Q/2023-08-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT®
45
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
