Scanning
5-14 ACUSON Cypress™ Operator’s Manual
Keeping Track of Saved Loops
As loops are saved for a patient, the Cypress system keeps track of them. In
Freeze, View, or Playback mode, the loop information is displayed in a counter
at the top right corner of the screen. For example:
Loop 1/5
03:55:40 PM
13 June 2005
The lines display the following information:
 The first line displays the number assigned to the currently displayed loop (1
in the example). The second number displays the total number of loops in
memory (5 in the example).
 The second line displays the time the current loop was captured.
 The third line displays the date the current loop was captured.
FIGURE 24. Loop Information
LOOP INFORMATION IS DISPLAYED:
1. IN VIEW MODE
2. WHEN THE FREEZE KEY IS PRESSED
AND THERE ARE LOOPS TEMPORARILY
STORED IN THE SCROLLING MEMORY
Loop 1/5
03:55:40 PM
13 June 2005
3V2c Pwr M
MI 0.9 TIs 0.1
Comp 2 PProc 3
GN 5/ /
45fps 16.2cm
Harmonic
