Scanning
5-32 ACUSON Cypress™ Operator’s Manual
Color Flow Soft Windows
Table 18 describes how the Soft Windows and their corresponding knobs on the
keyboard operate in Color Flow scanning.
TABLE 18. Color Flow Scanning Soft Windows Options
Window/Function Description
C Steer
(Vascular only)
Color Steering for the
7L3 transducer.
Changes the angle of the color box within the
2D
image. Press the corresponding Soft Window knob
to select
C STEER.
 To steer to the right, turn the knob clockwise.
 To steer to the left, turn the knob counterclock-
wise.
Depth Scanning depth is measured in centimeters and is
displayed on the top left corner of the screen (see
“Cypress System Data” on page 5-9). Scanning
depth varies with transducer frequency. The maxi-
mum scanning depth of the system is 24.4 cm.
 For a shallower depth, turn the knob counter-
clockwise.
 For a deeper depth, turn the knob clockwise.
Zoom
(Available only in active
scanning)
Allows you to select
and enlarge a portion
of the image.
Press the corresponding Soft Window knob to
select
ZOOM. This places the "zoom" box on the
image. Use the Trackball to position the Zoom box
 To change the magnification factor, turn the knob
clockwise.
 Press <ENTER> to enlarge the image.
 To reposition or resize the zoom box, turn the
knob counterclockwise.
Press the
ZOOM Soft Window knob to exit.
