ACUSON Cypress™ Operator’s Manual 5-7
Overview of the Scanning Process
When viewing saved loops, the Main knob controls Search and Play (displayed
on the bottom, right corner of the screen). Press the knob to switch between the
two modes.
Flagging Images
Saved frames, loops, and series can be flagged. The Flag function is available
when the system is in View or Freeze mode. When an image is flagged, a small
flag icon is displayed in the top, right corner of the screen.
To set the flag, turn the FLAG Soft Window knob clockwise.
To remove the flag, turn the FLAG Soft Window knob counterclockwise.
When data is flagged, the amount of data flagged depends on the status of the
PLAY LOOP/PLAY SERIES Soft Window. If PLAY LOOP is displayed in the Soft
Window, the currently displayed single loop or frame is flagged. If
PLAY SERIES
is displayed, the entire series of loops is flagged.
NOTE In Freeze mode, flagging does not save the data—you must also
press either
•SAVE or QSAVE to save the data as part of the patient's
study.
TABLE 13. Main Knob Controls When Viewing Loops
Control Function/Description
Search In Search mode, turning the knob allows a frame-by-frame
search.
To search forward, turn the knob clockwise.
To reverse the search, turn the knob counterclockwise.
Play When
PLAY is highlighted by pressing the Main knob, the PLAY
label changes to
NORMAL. NORMAL indicates the normal play-
back speed. Turn the Main knob counterclockwise to select
SLOW and clockwise to select FAST.
This function is available in all full-screen View modes and
Freeze modes when
PLAY is displayed in the Soft Window con-
trolled by the Main knob.
TO SWITCH
BETWEEN
SEARCH AND
PLAY, PRESS
THE MAIN KNOB
