Magneto Optical (MO) Disk Drive
The Cypress system may be provided with an optical disk device for image and
Patient Study storage. Details on the operation of the optical disk are provided
in the section, “Transferring Studies” on page 9-14.
The Cypress system uses a 3.5 inch magneto optical disk for removable stor-
age. Disks may need to be formatted prior to use. “Transferring Studies Using
the MO Drive” on page 9-22.
FIGURE 5. Using the MO Disk Drive
 To insert a disk into the system, load the disk as shown in Figure 5.
 To remove a disk, press the button located next to the disk bay.
NOTE: The system must have power to eject the disk when using the eject
button.
PRESS THE
EJECT BUTTON
TO REMOVE
THE DISK
3.5 INCH
MAGNETO
OPTICAL
DISK DRIVE
INSERT DISK
INTO DRIVE
