Scanning
5-4 ACUSON Cypress™ Operator’s Manual
Using Tools
Pressing the TOOLS function key opens a series of control buttons on the right
side of the screen. These buttons control secondary image functions. The tools
vary according to the active mode.
Use the Trackball and <
ENTER> key to click (i.e., select) a control button. A
menu opens. Select a function from the menu.
See the descriptions of each scanning mode on the following pages for informa-
tion about specific tools.
FIGURE 21. The TOOLS Function Key Displays the Tools Buttons
Apex Invert
Depth
Frequency
2D Gain
Compress
3V2c Pwr M
MI 1.0 TIs 0.1
Comp 2 Pproc 3
GN 5/ /
45fps 16.2cm
Harmonic
Text
THE TOOLS BUTTONS ARE LOCATED IN THE TOP RIGHT
CORNER OF THE SCREEN. IN 2D MODE, THE TOOLS BUT-
TONS ARE [IMAGE], [TEXT], [ROI] and [TIMER].
ROI
Timer
