Stress Echo
8-12 ACUSON Cypress™ Operator’s Manual
Stress Echo TOOLS
Pressing the TOOLS function key while in stress echo scanning mode displays
the Tools buttons, including a [
TIMER] button.
FIGURE 38. Stress Tools
The [
IMAGE], [TEXT], and [ROI] buttons function the same as they do in 2D mode
(see Table 17 on page 5-28 for an explanation of these buttons).
The [
TIMER] button has the following functions:
Start: Starts the timer clock.
Restart: Starts the timer clock once it has been stopped.
Stop: Stops the timer clock.
Off: Stops the timer clock and removes it from the screen.
Cancel: Closes the menu without changing the timer clock.
Start
Restart
Stop
Off
Cancel
3V2c PA Pwr M
MI 1.0 TIs 0.1
Compress 2
GN 5/ /
45fps 16.2cm
Harmonic
Text
STRESS
TOOLS
BUTTONS
SUB-MENU FOR
TIMER
ROI
Timer
Rest
