System Overview
1-12 ACUSON Cypress™ Operator’s Manual
Transporting the System
The Cypress system is a highly portable system, designed for use in a variety of
settings. Certain precautions should be taken when moving the system to
reduce the risk of injury and ensure reliable operation. See “Safety, Technical
Description, and Accuracy” on page 10-1 for further details.
NOTE: It is especially important to protect the display screen of the Cypress
system when transporting the unit. Always put the hinged keyboard
in the “up” position.
FIGURE 7. How to Move the Cypress System
Transporting the Cypress System in a Vehicle
Disconnect the transducers and store them in a separate packing case.
Place the system itself securely in a packing case or carrying case.
Secure the case within the vehicle to prevent it from moving or shifting.
Moving the Cypress System within a Building
Make sure that the transducer is securely placed in the transducer holder.
Make sure that all cables are properly secured and that no cables are hang-
ing loose.
ALWAYS PUT
KEYBOARD IN
“UP” POSITION
SECURE
TRANSDUCER IN
HOLDER OR
PACKING CASE
