ACUSON Cypress™ Operator’s Manual 2-1
CHAPTER 2 Keyboard &
General Controls
2
This chapter describes the Cypress system keyboard and controls. It includes
information on:
Using the Mode keys to select the type of scanning
Using the Trackball and <ENTER> keys
Using the time/gain compensation (TGC) slide-pots to adjust the depth-
related gain of the
2D image
How the function of the Main knob depends on the active mode of the system
Using the Soft Window knobs to control the soft windows options located on
the bottom of the screen
Using the Function keys
Using the Alphanumeric keys to enter text data
