Scanning
5-6 ACUSON Cypress™ Operator’s Manual
Viewing Saved Loops
Saved loops can be viewed at any time during an exam by pressing the VIEW
function key. The system displays the most recently saved loop or frame. Press
any Mode key to exit View.
TABLE 12. Viewing Saved Loops Soft Windows
Window Function/Description
Play All Plays each saved loop in a continuous rotation. When the
PLAY
ALL
knob is pressed, the system plays the saved loops in the
order they were saved. Press the
2D key to exit Play All mode.
Play
Loop/
Play
Series
Press the knob to switch between the two functions.
 To advance to the next loop/series, turn the knob clockwise.
 To return to the previous loop/series, turn the knob counter-
clockwise.
Delete The Delete function is available in both the Play Loop and Play
Series modes. When
PLAY LOOP is displayed, pressing or turn-
ing the
DELETE Soft Window knob deletes the currently dis-
played image data. When
PLAY SERIES is displayed, pressing or
turning the
DELETE Soft Window knob deletes the currently dis-
played series.
NOTE Deleted loops cannot be retrieved.
NOTE A study must contain at least one loop. Therefore, the
last loop or frame in a study cannot be deleted. For
example, if a study contains three loops and you try
to delete all three, the Cypress system will allow two
loops to be deleted—but not the final loop. To delete
the remaining loop, the entire study must be removed
from the patient’s file.
