ACUSON Cypress™ Operator’s Manual 1-15
Location of Fan and Vents
Location of Fan and Vents
Note the location of the Cypress system fan and vents in Figure 10. Make sure
that the fan and vents are never covered. Air should always be able to flow
freely around the Cypress system.
FIGURE 10. Location of Fan and Vents
THE FAN IS LOCATED ON
THE RIGHT SIDE OF THE
CYPRESS SYSTEM
VENTS ARE LOCATED
ON THE TOP AND
BACK OF THE
CYPRESS SYSTEM
