System Overview
1-2 ACUSON Cypress™ Operator’s Manual
Overview of the Cypress System
FIGURE 1. Overview of the Cypress System
KEYBOARD
TRANSDUCER
CONNECTOR
TILT
MONITOR
KEYBOARD
TILT
MECHANISM
ON/OFF
SWITCH
(ON BACK)
ECG
CONNECTOR
(ON BACK)
MAGNETO
OPTICAL
DRIVE
EXTERNAL
CONNECTORS
