Keyboard Overview
FIGURE 11. The Cypress System Keyboard
The Cypress system keyboard consists of:
 Seven Mode keys
 Two <ENTER> keys and Trackball
 Time/gain compensation (TGC) slide-pots
 The Main knob
 Four Soft Window knobs
 Six Function keys
 An alphanumeric keypad
