ACUSON Cypress™ Operator’s Manual 9-13
Connecting the Cypress System to a Network
Connecting the Cypress System to a Network
The Cypress system can be connected to a network if the network option has
been installed on the system. A standard RJ-45 network cable connects to the
port on the right side of the system.
FIGURE 40. Connecting Cypress System to a Network
Once the Cypress system is connected, complete the
DICOM setup as
described in “DICOM Setup for Network Transfers” on page 9-8.
Any time that you make changes, click [
PING] and then [VERIFY] to confirm the
connection to the network using the new settings. The Cypress system will
respond with a status message in the Test Result field.
RJ-45 JACK FOR 10/100 Mbps
ETHERNET CONNECTION
AND STATUS LEDs
