Scanning
5-26 ACUSON Cypress™ Operator’s Manual
Time
Increases the trigger
time in milliseconds.
As the knob is turned, the delay is increased and
the trigger moves. Press the corresponding Soft
Window knob to select
TIME.
To increase trigger times to the right of QRS, turn
the knob clockwise.
The current selection is displayed under the System
Data (for example, “40.0 ms”).
Frames
Selects the number of
frames that are pro-
duced in intermittent
mode.
Press the corresponding Soft Window knob to
select
FRAMES.
Turn the knob to select a number. The range is
from 1 to 16.
The current selection is displayed under the System
Data (for example, “3 Frames”).
TABLE 16. 2D Scanning Soft Windows Options
Window/Function Description
