ACUSON Cypress™ Operator’s Manual 5-29
2D Scanning
Text Adds text labels to an image. See “Adding Text to an Image” on
page 5-15 for details.
ROI (Region of Interest) Places a box in the
2D sector that allows the
capture of selected areas of the image. Use the Trackball to
move the box to the desired area.
Timer Procedure Timer — A timer is available for all exams. To
access the timer, follow these steps:
1. Press TOOLS and click the [TIMER] button.
2. Select [START] to display the timer.
Start: Starts the timer clock.
Restart: Starts the timer clock once it has been stopped.
Stop: Stops the timer clock.
Off: Stops the timer clock and removes it from the screen.
Cancel: Closes the menu without changing the timer
clock.
TABLE 17. 2D Tools Controls
Button Description
