ACUSON Cypress™ Operator’s Manual 5-47
Pulsed Wave Doppler (PW) Scanning
Scale
Adjusts the velocity
scale of the spectral
display
The range depends on the transducer frequency.
Press the corresponding knob to select Scale.
To increase the velocity setting, turn the knob
clockwise.
To decrease the velocity setting, turn the knob
counterclockwise.
Range Gate
Selects a size for the
range gate
Select a size. Press the corresponding knob to
select Range Gate.
For the 3V2c transducer, the sizes are:
5.0 mm, 6.0 mm, 7.0 mm, 8.5 mm, 10.0 mm,
15.0 mm, 20.0 mm
For the 7V3c transducer, the sizes are:
2.0 mm, 2.4 mm, 3.9 mm, 4.9 mm, 5.9 mm,
8.0 mm, 10.0 mm
For the 7L3 transducer, the sizes are:
1.0 mm, 2.0 mm, 3.0 mm, 4.0 mm, 6.0 mm,
8.0 mm, 10.0 mm
For the Acunav 10F and 8F transducers, the
sizes are:
1.7 mm, 2.1 mm, 3.3 mm, 4.3 mm, 5.3 mm,
8.0 mm, 10.0 mm
For the 4C1 transducer, the sizes are:
3.0 mm, 4.5 mm, 6.0 mm, 8.0 mm, 10.0 mm,
15.0 mm, 20.0 mm
For the V5M transducer, the sizes are: 2.0 mm,
2.4 mm, 3.9 mm, 4.9 mm, 5.9 mm, 8.0 mm,
13.0 mm
TABLE 22. PW Scanning Soft Windows Options
Window Function/Description
