Cardiac Calculations
6-8 ACUSON Cypress™ Operator’s Manual
5. The second cursor (endpoint) will appear. Use the Trackball to position the
cursor and then press <
ENTER> to complete the measurement.
6. Press CALC to exit the calculation package. Note that an index in green text
is displayed in the upper right portion of the screen. This index is stored with
the frame when the frame is saved for review at a later time.
TABLE 28. Measurement Index Table
Measurement Index Description
Single Upper Case
Letter (A)
A general measurement. Results are displayed in
the Selection Menu.
Single Lower Case
Letter (a)
A specific measurement. Results are displayed in
the Selection Menu, Report Menu, and Patient
Report.
MEASUREMENT INDEX IN
SELECTION MENU
Distance
A = 5.00 cm
Area
Volume
Left Ventricle Volumes
Left Ventricle Mass
Ventricles
LVOT, Valves & Atria
Qp Qs
Report
To Next Page
