Vascular Calculations
7-8 ACUSON Cypress™ Operator’s Manual
5. Press CALC to exit the calculation package. Note that an index in green text
is displayed in the upper right portion of the screen. This index is stored with
the frame when the frame is saved for review at a later time.
TABLE 34. Measurement Index Table
Measurement Index Description
Single Upper Case
Letter (A)
A general measurement. Results are displayed in
the Selection Menu.
Single Lower Case
Letter (a)
A specific measurement. Results are displayed in
the Selection Menu, Report Menu, and Patient
Report.
MEASUREMENT INDEX IN
SELECTION MENU
Velocity
A: = 1.25 m/s
PI
RI
Acceleration
Right Carotid
Left Carotid
Arterial
Venous
Ratios
Volume Flow
Report
