Store the extra connectors in case you purchase another stress system that
needs a different adapter.
FIGURE 36. ECG-to-BNC Connector and BNC-to-Stress System Plugs
ATTACH TO
ONE END OF
BNC CABLE
CONNECT TO ECG
PORT ON BACK OF
CYPRESS SYSTEM
ATTACH TO
OTHER END
OF BNC
CABLE
CONNECT
TO STRESS
SYSTEM
(USE THE
PLUG THAT
FITS YOUR
SYSTEM)
