Stress Echo
8-24 ACUSON Cypress™ Operator’s Manual
FIGURE 39. Quad-Screen Format for Stress Echo
PATIENT SCANNING
INFORMATION
Sel Quad
View
Next Loop
Slow
Pause
End
Smith, John
2 Stage Exercise
26 Aug 2005
07:11:14 AM
PRESS THE
MAIN KNOB TO
SWITCH
BETWEEN
PAUSE AND
THE SPEED
2D SOFT WINDOW
MENU OPTIONS
RestAP4
55 BPM
:10 ImpostAP4
123 BPM
RestAP2
55 BPM
:13 ImpostAP2
120 BPM
LOOP 2/5
LOOP 2/2
LOOP 1/1
LOOP 3/10
THE YELLOW BAR REPRESENTS
THE LENGTH (IN FRAMES) OF THE
CURRENTLY DISPLAYED LOOP
THIS IS A MULTIFUNCTIONAL
SOFT WINDOW. PRESS THE
KNOB TO CYCLE THROUGH THE
FUNCTIONS (START AND END)
AND THEN TURN THE KNOB TO
ADJUST THE FUNCTION.
THE QRS WAVE
