ACUSON Cypress™ Operator’s Manual 4-3
The Patient Menu
The Patient menu can be displayed in two different formats: by patient name, or
by individual patient studies. Click the [
PATIENT LIST/STUDY LIST] button to tog-
gle from one display format to the other.
FIGURE 15. The Patient Menu — Each Study as a Separate Item
Study: 0
ShutdownReportsSetupPatient
DOE, AB 36517 04/22/2000.. None <1
DOE, C 36285 10/26/1999.. None <1
DOE, C 36486 08/04/1999.. 2 Stage E <1
DOE, D 369387 09/02/1999.. None <1
DOE, E 2345686 05/25/2000.. Y None <1
DOE, MM 36286 06/17/2000.. Pharmacolo
<1
DOE, P 36790 07/23/1999.. 3 Stage E <1
DOE, Q 36137 03/23/2000.. None <1
DOE, R 36017 08/16/1999.. M None <1
DOE, S 369278 08/18/1999.. None <1
DOE, TT 36938 09/20/1999.. None <1
DOE, TT 36987 09/20/1999.. Y None <1
DOE, V 36832 10/29/1999.. Y None <1
DOE, WE 36038 10/30/1999.. None <1
DOE, WR 36517 04/04/2000.. None <1
Storage [MBytes]
Free: 3535
Si
Patient Name Patient Id
Protocol
Date
Arc..
THIS DISPLAY SHOWS EACH
STUDY AS A SEPARATE ITEM
WHERE THE LISTS CAN BE
SORTED. TO SORT A COLUMN,
CLICK THE LABEL AT THE TOP.
FOR EXAMPLE, TO SORT BY
PATIENT CLICK THE “PATIENT
NAME” LABEL ONCE TO SORT
FROM “A” TO “Z”; CLICK AGAIN
TO SORT FROM “Z” TO “A”.
SWITCH BETWEEN
THE PATIENT LIST AND
THE STUDY LIST
TO RESIZE COLUMNS:
PLACE THE CURSOR ON
THE LINE BETWEEN THE
COLUMN LABELS, HOLD
DOWN THE <ENTER> KEY
AND USE THE TRACKBALL
TO MOVE THE LINE TO
RESIZE THE COLUMN.
TO VIEW A STUDY:
1. CLICK ON THE STUDY
TO HIGHLIGHT IT.
2. CLICK THE [ACTI-
VATE] BUTTON.
3. PRESS THE VIEW
FUNCTION KEY OR
DOUBLECLICK THE
STUDY FOR IMMEDI-
ATE REVIEW.
Activate
Edit
Remove
New
Study
Patient
List
New
Patient
Send
Worklist
Print
THE ARCHIVED
HEADING SPECIFIES
WHETHER A STUDY
HAS BEEN ARCHIVED.
A “Y” MEANS THE
STUDY HAS BEEN
ARCHIVED.
AN “M” MEANS THE
STUDY WAS ARCHIVED
AND THEN MODIFIED.
