Engineering via SICAM WEB
362 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
Category Parameter Meaning
Process data measured
value
SID-BSE Source identification basic system element
SID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254; if
automatic, the SID will be learned
SID-SSE Source identification supplementary system
element
Archive_(MV) The data point is recorded in the decentral-
ized archive
Text_(MV) The data point is displayed with this name
(max. 13 characters)
GroupNbr_(MV) The data point is displayed in the cockpit in
this group (1…32)
GroupPos_(MV) The data point is displayed in the cockpit on
this position (1…256)
X_0%_(MV) Value adaptation: Lower limit of the used
measuring range in the external (protocol
specific) format. The corresponding internal
value is defined at Y_0%.
X_100%_(MV) Value adaptation: Upper limit of the used
measuring range in the external (protocol
specific) format. The corresponding internal
value is defined at Y_100%.
Y_0%_(MV) Value adaptation: Lower limit of the used
measuring range in the selected internal
format. The internal format is defined at TI
(type identification). The corresponding ex-
ternal value is defined at X_0%.
Y_100%_(MV) Value adaptation: Upper limit of the used
measuring range in the selected internal
format. The internal format is defined at TI
(type identification). The corresponding ex-
ternal value is defined at X_100%.
Decimal_places_(MV) Count of decimal places (max. 7)
Unit_(MV) The value is displayed with this unit text
(max. 8 characters)
Process data message Event_(MSG) The data point is displayed in the event list
Alarm_(MSG) The data point is displayed in the alarme list
Archive_(MSG) The data point is recorded in the decentral-
ized archive
Text_(MSG) The data point is displayed with this name
(max. 13 characters)
State_TextOn_(MSG) The state ON for single or double point infor-
mation is displayed with this name (max.
6 characters)
State_TextOff_(MSG) The state OFF for single or double point
information is displayed with this name (max.
6 characters)
State_TextFlt_(MSG) The state faulty position for double point
information is displayed with this name (max.
6 characters)
State_TextInt_(MSG) The state intermediate position for double
point information is displayed with this name
(max. 6 characters)
