Category Parameter Meaning
Cockpit_GroupNbr_(MSG) The data point is displayed in the cockpit in
this group (1…32)
Cockpit_GroupPos_(MSG) The data point is displayed in the cockpit on
this position (1…255)
SID-BSE Source identification basic system element
SID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254; if
automatic, the SID will be learned
SID-SSE Source identification supplementary system
element
Protocol element control
message
Control_function_(PRE)
• 0...239 = function defined by protocol ele-
ment
• 240 = GI request
• 241 = reserved
• 242 = control location
• 244 = CASDU selective GI request
• 245...255 = reserve for further BSE func-
tions
Edge_(PRE)
• Positive edge
• Negative edge
• State (0 = function, 1 = function + 1)
PRE_(CM) Protocol element number
• PRE0…PRE3
• distribute over multimaster function
Station
• 0…99 = station number
• 125 = to all stations
• 255 = not used
Additional_parameter_(PRE) 0...65535 = meaning for each function de-
fined by the PRE firmware
SID-BSE Source identification basic system element
SID-ST Source identification station number if mul-
tipoint traffic mode 0…99 if R-SID 0…254; if
automatic, the SID will be learned
SID-SSE Source identification supplementary system
element
104-Address
TI Type identification according to
IEC 60870-5-101/104
• Single-point information
• Single command
Protocol element return
information message
Return_information_function_
(PRE)
PRE_(RM) Protocol element number (0…3)
Station Station number (selective 0...99; to all sta-
tions; station not used)
Redundancy control
message
Control_function_(RED)
• User priority
• A/P-control
• Key switch
• Listening mode-control
• A/P-control with failed SCA-RS
• Switch-over disabled
Failure_behavior_(RED)
• Terminate binary information
• Maintain status
BSE_(RED) Basic system element
