Siemens Simodrive 611 - Technical Data of the Supplementary Components

6
05.01
6.3 Technical data
6-175
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
6.3.2 Technical data of the supplementary components
Components Component
Order No.
Supply
voltage
Supply
current
Observe phase
sequence!
Degr.
of pro-
tection
Weight
[kg]
Mounted fan for internal
and external cooling
6SN1162–
0BA02–
0AAV
3–ph. 360 to
510 VAC
45 to 65 Hz
0.2 A to 0.3 A Direction of rota-
tion refer to the
arrow on the fan
IP 44 4
Hose cooling package for
an individual module com-
prising:
2x module connecting
flange, hose
2000 mm
1x cabinet connecting
flange
1x radial fan with cabinet
connecting flange
1)
(refer to Fig. 2-4)
6SN1162–
0BA03–0AAV
3–ph. 360 to
457 VAC
47.5 to
62.5 Hz
1.0 A +20% Ccw direction of
rot. when viewing
the rotor
IP 54 8
Hose cooling package for
2–tier configuration of I/R
55 kW and
PM 85 A comprising: 4x
module connecting flange,
hose
2000 mm
1x cabinet connecting
flange
1x radial fan with cabinet
connecting flange
1)
(refer to Fig. 2-4)
6SN1162–
0BA03–0CAV
3–ph. 360 to
457 VAC
47.5 to
62.5 Hz
1.0 A +20% Ccw direction of
rot. when viewing
the rotor
IP 54 8
Motor protection circuit–
breaker
Size S00:
Setting value 0.3 A
Setting value 1 A
Quantity S0
Setting value 0.3 A
Setting value 1 A
3RV1011–0DA10 0.22–0.32 A
3RV1011–0KA10 0.9–1.25 A
3RV1021–0DA10 0.22–0.32 A
3RV1011–0KA10 0.9–1.25 A
Hot air deflection plate 6SN1162–
0BA01–0AA0
Required for UI and pulsed–resistor modules when the pulsed resistor
is utilized to its maximum ( > 200 W ) (refer to Section 13, dimension
drawings)
1)
Replacement filter element: Order No. 8MR 1191–0A0
Ordering location: Pfannenberg GmbH
Postfach 80747
21007 Hamburg
!
Warning
The fan may only be commissioned, if it is electrically connected with the mo-
dule housing (the PE of the fan is connected via the module housing).
Cooling
components
6 Infeed Modules
