9
05.01
9.12 Operation at power failure
9-299
Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) 05.01 Edition
9.12.3 DC link buffering
The energy, available in the DC link of the drive units is calculated as follows at
power failure:
E = 1/2 * C * (V
DC
link
2
V
min
2
)
In this case, E= energy in Watt seconds [Ws]
C= total capacitance of the DC link in Farad [F]
V
DC
link
= DC link voltage (response limit, line supply failure)
V
min
= lower limit for safe reliable operation
(taking into account the motorspecific EMF, in any case,
above the switchoff threshold of e.g.350V)
Example:
For C= 6000µF (refer to Table 9-3, 1. line) 20% = 4800 µF
V
DC
link
= 550V
V
min
= 350V
is obtained as follows:
E = 1/2 * 4800F *((550V)
2
(350V)
2
) = 432Ws
This energy, under load conditions is available for a time of
t
min
= E / P
max
*
in order to initiate emergency retraction.
In this case, t
min
= buffer time in milliseconds [ms]
P
max
= power in Kilowatt [kW]
= efficiency of the drive unit
For the example above, with:
E = 432Ws
P
max
= 16kW (refer to Table 9-3, 1. line)
= 0.90
is obtained as follows:
t
min
= 432Ws / 16kW * 0.9 = 24.3ms
as minimum achievable buffer duration for emergency retraction.
