1.2 Engineering steps
1-21
Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
1.2 Engineering steps
Note
When engineering/configuring SIMODRIVE 611 drive systems, it is assumed
that the motors being used are known.
Reference: /PJM/ Planning Guide, Motors
A SIMODRIVE drive group is engineered in 2 phases:
S Phase 1 Selecting the components (refer to Fig. 1-4)
S Phase 2 Connection configuration (refer to Fig. 1-5)
Starting from the required torque, the motor is first selected followed by the drive
module and the various encoder evaluation versions.
When required, a second engineering phase can following the first one. Here,
the appropriate circuit recommendations and measures are taken into account.
Note
A PC tool is available to configure the 6SN series, e.g.:
S NCSD configurator
Please contact your local Siemens office for further information.
The functions of the control modules are described in this Planning Guide in
the form of bullet points and where relevant, with limit values. Please refer to
the appropriate documentation for additional details.
Basic engineering information/instructions and detailed ordering information are
provided in Catalogs NC 60 and NC Z.
Procedure
1 Overview of the Drive System
