Siemens Simodrive 611 Planning Guide

9
05.01
9.3 Axis expansion using the monitoring module
9-234
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
9.3.2 Connection example, pulse enable
NE module Monitoring module
Ready/
fault message
S1.2
72
73.1
FR– 19
1)
19 FR–
Ready/
fault message
S1.2
63 IF
9 FR+
0 V
To the external power supply
1)
2)
Fig. 9-6 Instantaneous shutdown, pulse enable
NE module Monitoring module
Ready/
fault message
S1.2
72
73.1
FR– 19
1)
19 FR–
Ready/
fault message
S1.2
63 IF
9 FR+
0 V
To the external power supply
1)
1
A
3
A
B1 B3
2
A
18
15
16
+24 V
–KT
–KT
15
18
2)
3)
Fig. 9-7 Delayed shutdown, pulse enable
1) Settings, S1.2 ready/fault signal, refer to Section 6.1.
2) The shutdown is shown in a simplified fashion without any contacts of the drive–related control
3) Time relay with delayed drop–out with auxiliary function, e.g. 3RP1505–1AP30,
t(v) > max. braking time of the drive after the monitoring module.
Instantaneous
shutdown
Delayed shutdown
9 Important Circuit Information
