Table 2-1 Ambient conditions
Designation Description
Transport and
Temperature range –40 °C – +70 °C
storage
Moisture
condensation
Annual average U = 75 %
td = 17 °C
temperature t
d
and relative air
30 days (24h) annually U = 95 %
td = 24 °C
humidity U
These days should be naturally distributed over the year.
On all other days (<24 h)
but still maintaining the annual ave-
rage
U = 85 %
td = 24 °C
Applicable standards DIN IEC 68–2–1
DIN IEC 68–2–2
DIN IEC 68–2–3
DIN VDE 0160, Section 5.2.1.3
EN 50178
Climatic am-
bient conditions
in operation
Temperature range:
for power module/NE
modules (100%
load):
Current/power de–
rating above +40 °C:
0 °C – +55 °C
+55 °C
2.5 % / °C
Moisture condensa-
tion temperature t
d
Annual average U = 75 %
td = 17 °C
and relative air humi-
dity U
on 30 days (24h) over the year U = 95 %
td = 24 °C
These days should be naturally distributed over the year.
On all other days (<24 h)
but still maintaining the annual ave-
rage
U = 85 %
td = 24 °C
Temperature change within one hour:
within 3 minutes:
max. 10 K
max. 1 K
Moisture condensa-
tion
Not permissible
Air pressure min. 860 mbar (86 kPa)
max. 1080 mbar (108 kPa)
Gases which can
have a negative
effect on the function
acc. to DIN 40046, Part 36 and Part 37
Applicable standards DIN IEC 68–2–1
DIN IEC 68–2–2
DIN IEC 68–2–3
DIN VDE 0160, Section 5.2.1.3
EN 50178
2.3 Motor selection
The Planning Guide, Motors is used to select the drive motors
The selected motor and the (short–time) overload capability defines the size of
the power module (refer to Section 4).
Selection
