Siemens Simodrive 611 Planning Guide

2 System Configuration
2
05.01
2.7 Infeed modules
2-41
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
2.7.2 Internal cooling
min. 100 mm
clearance
min. 100 mm
clearance
Fig. 2-6 Power module with inserted control module, internal cooling
Note
The power loss is dissipated inside the cabinet which means that this has to be
taken into account when designing the cabinet cooling system.
