4.4 Interface overview
4-97
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
4.4 Interface overview
Table 4-12 1-axis module
Term.
No.
Desig. Function
Type
1)
Typ. voltage/ limit values Max. cross–sect.
U2
V2
W2
1 A Motor connection O 3–ph. 430 V AC refer to Section 4.1
PE Protective conductor
Protective conductor
I
I
0 V
0 V
2 screws
P600
M600
DC link
DC link
I/O
I/O
+300 V
–300 V
Busbar
Busbar
Table 4-13 2-axis power modules
Term.
No.
Desig. Function
Type
1)
Typ. voltage/ limit values Max. cross–sect.
U2
V2
W2
1 A Motor connection for axis 1 O 3–ph. 430 V AC refer to Section 4.1
U2
V2
W2
2 A Motor connection for axis 2 O 3–ph. 430 V AC refer to Section 4.1
PE Protective conductor
Protective conductor
I
I
0 V
0 V
3 screws
P600
M600
DC link
DC link
I/O
I/O
+300 V
–300 V
Busbar
Busbar
