6
05.01
6.6 DC link options
6-198
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
6.6.4 External pulsed resistors
Using the external pulsed resistors, the heat loss can be dissipated outside the
cabinet. External pulsed resistors are always required for the 28 kW UI module.
Shielded cables must be used to connect the pulsed resistors.
Notice
The pulsed resistor is equipped with a temperature monitoring function, which
protects it against overheating.
Table 6-17 UI modules with pulsed resistors
Pulsed resistors, technical data
External pulsed
resistor 0.3/25
kW
External pulsed
resistor 1.5/25
kW
Internal pulsed
resistor 0.3/25
kW
Internal pulsed
resistor 0.2/10
kW
Order No. 6SN1113–
1AA00–0DA0
6SN1113–
1AA00–0CA0
– –
Integrated
in
– – UI 10 kW,
pulsed resistor
module
UI 5 kW
Can be
used for
UI module 28
kW
UI module 28
kW
– –
Can be
used for –
Pulsed resistor
module
6SN1113–
1AB0V–0BAV
– –
Pn 0.3 kW 1.5 kW 0.3 kW 0.2 kW
P
max
25 kW 25 kW 25 kW 10 kW
E
max
7.5 kWs 180 kWs 7.5 kWs 13.5 kWs
Degree of
protection
IP 54 IP20 refer to module refer to module
Dimension drawings, refer to Section 13
6 Infeed Modules
