Siemens Simodrive 611 - Dimension Drawings

2 System Configuration
2
05.01
2.7 Infeed modules
2-40
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
Minimum,
300 mm
Fig. 2-5 System configuration with hose cooling (only for 300 mm modules)
Note
DC link connection, refer to Section 10.1.3
Connection details for the DC link adapter set, refer to the dimension drawings
