2 System Configuration
2
05.01
2.6 Control modules
2-36
Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) 05.01 Edition
Table 2-3 Comparison table
Control module with Standard
interface
Performance
regulation
Max. electrical base
frequency for the motor:
600 Hz 1333 Hz
Encoder limiting frequency: 200 kHz 350 kHz
Pulse multiplication: 128 2048
Maximum cable length for
encoders with voltage
signal
50 m 50 m
Motor encoder system and direct measuring systems
Incremental encoder sin/
cos
1 Vpp:
yes yes
Absolute value encoder En-
Dat:
yes yes
Prerequisites for
SINUMERIK Safety
Integrated:
yes with DMS yes with DMS
Operation of 1FN linear
motors:
yes
Applications: Standard
production machines
Precision machines
2.6.9 Control modules with digital setpoint interface for hydraulic/
analog linear drives HLA/ANA
The digital SIMODRIVE 611 HLA control module is designed to control and re-
gulate electrohydraulic control values for hydraulic linear axes in conjunction
with SINUMERIK 840D. Up to two hydraulic axes can be controlled with the
module. An HLA module
is obtained by inserting the control module in the 50 mm wide universal empty
housing.
This module can be integrated directly next to the SIMODRIVE 611 drive group
both with the mechanical as well as the electrical interfaces, such as equipment
bus, drive bus and DC link busbars.
The HLA control module contains the control structures for an electronic control
loop with high dynamic response characteristics. The HLA control module gene-
rates the power supply for the control valves and shutoff valves from an exter-
nal DC power supply (e.g. SITOP power, refer to NC 60 Catalog) with a rated
voltage of 26.5V.
An analog axis with speed setpoint interface $10 V can also be controlled
using the HLA control module. In this case, an appropriate axis must be selec-
ted. As far as the coarse structure is concerned, the control operates as D/A
converter for the setpoint and communicates the position information from the
encoder to the position controller in the SINUMERIK 840D via the drive bus.
Hydraulic linear
drive (HLA)
