Siemens Simodrive 611 Planning Guide

6
05.01
6.5 Monitoring module
6-186
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
6.5.3 Technical data (supplements the general technical data)
Table 6-8 Technical data, monitoring module
Power loss 70 W
Alternative, rated supply voltage
DC link
600/625/690 V DC
Cooling type Non–ventilated
Weight 4 kg
6.5.4 Checking the permissible power supply rating
The infeed or monitoring module used offers a basic equipping of the electro-
nics (EP values) and gating power supply (AP values).
The power supply requirement of a drive group is determined using Table 6-12.
The number of all of the modules used should be entered. It is the product of
»assessment factor, individual module« and »number of modules«.
If one of these values is exceeded, then an (additional) monitoring module must
be provided. In this case, Table 6-12 must be re–applied for the module group,
which is supplied from the monitoring module.
The monitoring module must be located to the left in front of the modules to be
monitored.
6 Infeed Modules
