SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
Overview of the Drive System
1.1 Overview of SIMODRIVE 611
Supply
Transformer
(optional)
Reactor
Cables, reactors,
VPM, cable protection
Motor
Closed–
loop con-
trol
e.g.:
611 analog
611 digital
611 universal
810D
Switches, contactors, fuses
Filter
Section 3
Section 6
G
Motor with position/
speed sensing
Section 7
Power modulePower module
Closed–
loop control
Section 5
Section 4
optional
Supply
Fig. 1-1 Principle system configuration
