Siemens Simodrive 611 Planning Guide

1
05.01
1.1 Overview of SIMODRIVE 611
1-20
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
Note
Siemens guarantees a satisfactory and reliable operation of the drive system
as long as only original SIMODRIVE system components are used in
conjunction with the original accessories described in this Planning Guide and
in Catalog NC 60.
The user must take into consideration the appropriate engineering specifica-
tions.
The drive converter system is designed for installation in an electrical cabinet
which is designed and implemented in compliance with the relevant Standards
for processing machines/machine tools, especially EN 60204.
Description The drive converter system comprises the following modules (refer to Fig. 1-2
and 1-3):
S Transformer
S Switching and protecting elements
S Line filter
S Commutating reactors
S Infeed modules
S Power modules
S Control modules harmonized with the application technology and motor
types
S Special modules and additional accessories
Different cooling types are available for the output–dependent supply infeed and
drive modules.
S Internal cooling
S External cooling
S Hose cooling
1 Overview of the Drive System

Siemens Simodrive 611 Specifications

General

Brand	Siemens
Model	Simodrive 611
Category	Media Converter
Language	English
