SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
Abbreviations and Terminology
A for Analog
D for Digital
U for Universal
UE for Universal Eco
Control board with analog interface
Control board with digital interface
General term for main spindle and feed modules
Electronics weighting factor
Encoder–Data–Interface (bi–directional synchronous–serial interface)
Module with heatsink for insertion, cooling on the customer’s side
Feed drive module
High–resolution position actual value
Infeed regenerative feedback module with controlled DC link voltage
Induction Motor
Induction Rotating Motor
Module with integrated heatsink, in some cases with pipe connection
L2 distributed periphery
Motion–Control–Unit (single–axis positioning board)
Monitoring module
Multi Point Interface
Machine Readable Product Designation
Main spindle module
Option board, main spindle options for FD module
611 A
611 D
611 U
611 UE
Analog closed–
loop control
Digital closed–
loop control
Drive module
EP
EnDat
External cooling
FD module
HGL
I/R module
IM
IRM
Internal cooling
L2DP
MCU
Monitoring module
MPI
MRPD
MSD module
MSD option
