Siemens Simodrive 611 Planning Guide

3
05.01
3.4 Direct position sensing
3-65
 Siemens AG 2001 All rights reserved
SIMODRIVE 611 Planning Guide (PJU) – 05.01 Edition
Red
Black
M5x12 max.
O10.5mm
Power supply
+ –
Fig. 3-9 Example of a connection at 6SN1118–0DG23–0AA1/–0DH23–0AA1
Red
Black
M5x12 max.
O10.5mm
Power supply
+ –
Fig. 3-10 Example of a connection at 6SN1115–0BA11–0AA1
3 Motor Selection, Position/Speed Sensing
