Siemens SIPROTEC 7UM62 User Manual

Appendix
A.7 Settings
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
587
8505 MEAS. VALUE 3> Threshold Disabled
P
Q
Delta P
UL1E
UL2E
UL3E
UE
U0
U1
U2
UE3h
IEE1
IEE2
3I0
I1
I2
PHI
PF
Transducer 1
Disabled Measured Value for Threshold
MV3>
8506 THRESHOLD MV3> Threshold -200 .. 200 % 100 % Pickup Value of Measured Value
MV3>
8507 MEAS. VALUE 4< Threshold Disabled
P
Q
Delta P
UL1E
UL2E
UL3E
UE
U0
U1
U2
UE3h
IEE1
IEE2
3I0
I1
I2
PHI
PF
Transducer 1
Disabled Measured Value for Threshold
MV4<
8508 THRESHOLD MV4< Threshold -200 .. 200 % 100 % Pickup Value of Measured Value
MV4<
8509 MEAS. VALUE 5> Threshold Disabled
P
Q
Delta P
UL1E
UL2E
UL3E
UE
U0
U1
U2
UE3h
IEE1
IEE2
3I0
I1
I2
PHI
PF
Transducer 1
Disabled Measured Value for Threshold
MV5>
8510 THRESHOLD MV5> Threshold -200 .. 200 % 100 % Pickup Value of Measured Value
MV5>
Addr. Parameter Function C Setting Options Default Setting Comments
