Appendix
A.8 Information List
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
594
- Control Authority (Cntrl Auth) Cntrl Authority IntSP on
off
* LED BO
- Controlmode LOCAL (ModeLO-
CAL)
Cntrl Authority IntSP on
off
* LED BO
- Reset Minimum and Maximum
counter (ResMinMax)
Min/Max meter IntSP
_Ev
on * LED BI BO
- Reset meter (Meter res) Energy IntSP
_Ev
on * LED BI BO
- Error Systeminterface (SysIn-
tErr.)
Protocol IntSP on
off
* LED BO
1 No Function configured (Not con-
figured)
Device SP
2 Function Not Available (Non Exis-
tent)
Device SP
3 >Synchronize Internal Real Time
Clock (>Time Synch)
Device SP_E
v
* * * LED BI BO 135 48 1 No
4 >Trigger Waveform Capture
(>Trig.Wave.Cap.)
Osc. Fault Rec. SP * * m LED BI BO 135 49 1 Yes
5 >Reset LED (>Reset LED) Device SP * * * LED BI BO 135 50 1 Yes
7 >Setting Group Select Bit 0 (>Set
Group Bit0)
Change Group SP * * * LED BI BO 135 51 1 Yes
009.0100 Failure EN100 Modul (Failure
Modul)
EN100-Modul 1 IntSP on
off
**LEDBO
009.0101 Failure EN100 Link Channel 1
(Ch1) (Fail Ch1)
EN100-Modul 1 IntSP on
off
**LEDBO
009.0102 Failure EN100 Link Channel 2
(Ch2) (Fail Ch2)
EN100-Modul 1 IntSP on
off
**LEDBO
15 >Test mode (>Test mode) Device SP * * * LED BI BO 135 53 1 Yes
16 >Stop data transmission
(>DataStop)
Device SP * * * LED BI BO 135 54 1 Yes
51 Device is Operational and Pro-
tecting (Device OK)
Device OUT ON
OFF
* * LED BO 135 81 1 Yes
52 At Least 1 Protection Funct. is
Active (ProtActive)
Device IntSP ON
OFF
**LEDBO70181Yes
55 Reset Device (Reset Device) Device OUT ON * * LED BO
56 Initial Start of Device (Initial Start) Device OUT ON * * LED BO 70 5 1 No
67 Resume (Resume) Device OUT ON * * LED BO
68 Clock Synchronization Error
(Clock SyncError)
Supervision OUT ON
OFF
**LEDBO
69 Daylight Saving Time (DayLight-
SavTime)
Device OUT on
off
**LEDBO
70 Setting calculation is running
(Settings Calc.)
Device OUT ON
OFF
**LEDBO70221Yes
71 Settings Check (Settings Check) Device OUT * * * LED BO
72 Level-2 change (Level-2 change) Device OUT ON
OFF
**LEDBO
73 Local setting change (Local
change)
Device OUT * * *
110 Event lost (Event Lost) Supervision OUT_
Ev
ON * * LED BO 135 130 1 No
113 Flag Lost (Flag Lost) Supervision OUT ON * m LED BO 135 136 1 Yes
125 Chatter ON (Chatter ON) Device OUT on
off
* * LED BO 135 145 1 Yes
140 Error with a summary alarm
(Error Sum Alarm)
Supervision OUT * * * LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
