Siemens SIPROTEC 7UM62 User Manual

Appendix
A.8 Information List
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
598
1508 >Failure temperature input
(>Fail.Temp.inp)
Therm. Overload SP on
off
**LEDBIBO16781Yes
1511 Thermal Overload Protection
OFF (Th.Overload OFF)
Therm. Overload OUT on
off
* * LED BO 167 11 1 Yes
1512 Thermal Overload Protection
BLOCKED (Th.Overload BLK)
Therm. Overload OUT on
off
on off * LED BO 167 12 1 Yes
1513 Overload Protection ACTIVE
(Overload ACT)
Therm. Overload OUT on
off
* * LED BO 167 13 1 Yes
1514 Failure temperature input
(Fail.Temp.inp)
Therm. Overload OUT on
off
* * LED BO 167 14 1 Yes
1515 Overload Current Alarm (I alarm)
(O/L I Alarm)
Therm. Overload OUT on
off
* * LED BO 167 15 1 Yes
1516 Thermal Overload Alarm (O/L Θ
Alarm)
Therm. Overload OUT on
off
* * LED BO 167 16 1 Yes
1517 Thermal Overload picked up
(O/L Th. pick.up)
Therm. Overload OUT on
off
* * LED BO 167 17 1 Yes
1519 Reset memory for thermal replica
O/L (RM th.rep. O/L)
Therm. Overload OUT on
off
* * LED BO 167 19 1 Yes
1521 Thermal Overload TRIP (ThOver-
load TRIP)
Therm. Overload OUT * on * LED BO 167 21 2 Yes
1720 >BLOCK direction I>> stage
(>BLOCK dir.)
O/C Prot. I>> SP on
off
**LEDBIBO60181Yes
1721 >BLOCK I>> (>BLOCK I>>) O/C Prot. I>> SP * * * LED BI BO
1722 >BLOCK I> (>BLOCK I>) O/C Prot. I> SP * * * LED BI BO
1801 O/C fault detection stage I>>
phase L1 (I>> Fault L1)
O/C Prot. I>> OUT * on off * LED BO 60 46 2 Yes
1802 O/C fault detection stage I>>
phase L2 (I>> Fault L2)
O/C Prot. I>> OUT * on off * LED BO 60 47 2 Yes
1803 O/C fault detection stage I>>
phase L3 (I>> Fault L3)
O/C Prot. I>> OUT * on off * LED BO 60 48 2 Yes
1806 O/C I>> direction forward (I>> for-
ward)
O/C Prot. I>> OUT * on off * LED BO 60 208 2 Yes
1807 O/C I>> direction backward (I>>
backward)
O/C Prot. I>> OUT * on off * LED BO 60 209 2 Yes
1808 O/C prot. I>> picked up (I>>
picked up)
O/C Prot. I>> OUT * on off * LED BO 60 210 2 Yes
1809 O/C I>> TRIP (I>> TRIP) O/C Prot. I>> OUT * on m LED BO 60 211 2 Yes
1811 O/C fault detection stage I>
phase L1 (I> Fault L1)
O/C Prot. I> OUT * on off * LED BO 60 50 2 Yes
1812 O/C fault detection stage I>
phase L2 (I> Fault L2)
O/C Prot. I> OUT * on off * LED BO 60 51 2 Yes
1813 O/C fault detection stage I>
phase L3 (I> Fault L3)
O/C Prot. I> OUT * on off * LED BO 60 52 2 Yes
1815 O/C I> TRIP (I> TRIP) O/C Prot. I> OUT * on m LED BO 60 71 2 Yes
1883 >BLOCK inverse O/C time pro-
tection (>BLOCK O/C Ip)
O/C Prot. Ip SP * * * LED BI BO
1891 O/C protection Ip is switched OFF
(O/C Ip OFF)
O/C Prot. Ip OUT on
off
* * LED BO 60 180 1 Yes
1892 O/C protection Ip is BLOCKED
(O/C Ip BLOCKED)
O/C Prot. Ip OUT on
off
on off * LED BO 60 181 1 Yes
1893 O/C protection Ip is ACTIVE (O/C
Ip ACTIVE)
O/C Prot. Ip OUT on
off
* * LED BO 60 182 1 Yes
1896 O/C fault detection Ip phase L1
(O/C Ip Fault L1)
O/C Prot. Ip OUT * on off * LED BO 60 184 2 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
