Appendix
A.8 Information List
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
597
581 Primary fault current IL3 Side2
(IL3 S2:)
P.S ys te m D ata 2 V I * O N
OFF
150 192 4 No
916 Increment of active energy
(WpΔ=)
Energy -
917 Increment of reactive energy
(WqΔ=)
Energy -
1020 Counter of operating hours
(Op.Hours=)
Statistics VI
1202 >BLOCK IEE>> (>BLOCK
IEE>>)
Sens. E Fault SP on
off
* * LED BI BO 151 102 1 Yes
1203 >BLOCK IEE> (>BLOCK IEE>) Sens. E Fault SP on
off
* * LED BI BO 151 103 1 Yes
1221 IEE>> picked up (IEE>> picked
up)
Sens. E Fault OUT * on off * LED BO 151 121 2 Yes
1223 IEE>> TRIP (IEE>> TRIP) Sens. E Fault OUT * on * LED BO 151 123 2 Yes
1224 IEE> picked up (IEE> picked up) Sens. E Fault OUT * on off * LED BO 151 124 2 Yes
1226 IEE> TRIP (IEE> TRIP) Sens. E Fault OUT * on * LED BO 151 126 2 Yes
1231 >BLOCK sensitive earth current
prot. (>BLOCK Sens. E)
Sens. E Fault SP * * * LED BI BO
1232 Earth current prot. is swiched
OFF (IEE OFF)
Sens. E Fault OUT on
off
* * LED BO 151 132 1 Yes
1233 Earth current prot. is BLOCKED
(IEE BLOCKED)
Sens. E Fault OUT on
off
on off * LED BO 151 133 1 Yes
1234 Earth current prot. is ACTIVE
(IEE ACTIVE)
Sens. E Fault OUT on
off
* * LED BO 151 134 1 Yes
1403 >BLOCK breaker failure
(>BLOCK BkrFail)
Breaker Failure SP * * * LED BI BO
1422 >Breaker contacts (>Break. Con-
tact)
Breaker Failure SP on
off
* * LED BI BO 166 120 1 Yes
1423 >ext. start 1 breaker failure prot.
(>ext.start1 B/F)
Breaker Failure SP on
off
* * LED BI BO 166 121 1 Yes
1441 >ext. start 2 breaker failure prot.
(>ext.start2 B/F)
Breaker Failure SP on
off
* * LED BI BO 166 122 1 Yes
1442 >int. start breaker failure prot.
(>int. start B/F)
Breaker Failure SP on
off
* * LED BI BO 166 123 1 Yes
1443 Breaker fail. started intern (int.
start B/F)
Breaker Failure OUT on
off
* * LED BO 166 190 1 Yes
1444 Breaker failure I> (B/F I>) Breaker Failure OUT on
off
* * LED BO 166 191 1 Yes
1451 Breaker failure is switched OFF
(BkrFail OFF)
Breaker Failure OUT on
off
* * LED BO 166 151 1 Yes
1452 Breaker failure is BLOCKED
(BkrFail BLOCK)
Breaker Failure OUT on
off
on off * LED BO 166 152 1 Yes
1453 Breaker failure is ACTIVE (Bkr-
Fail ACTIVE)
Breaker Failure OUT on
off
* * LED BO 166 153 1 Yes
1455 Breaker failure protection: picked
up (B/F picked up)
Breaker Failure OUT * on off * LED BO 166 155 2 Yes
1471 Breaker failure TRIP (BrkFailure
TRIP)
Breaker Failure OUT * on m LED BO 166 171 2 Yes
1503 >BLOCK thermal overload pro-
tection (>BLK ThOverload)
Therm. Overload SP * * * LED BI BO
1506 >Reset memory for thermal
replica O/L (>RM th.rep. O/L)
Therm. Overload SP on
off
**LEDBIBO
1507 >Emergency start O/L (>Em-
er.Start O/L)
Therm. Overload SP on
off
* * LED BI BO 167 7 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
