Siemens SIPROTEC 7UM62 User Manual

Appendix
A.8 Information List
SIPROTEC, 7UM62, Manual
C53000-G1176-C149-7, Release date 03.2010
596
266 Failure: Phase Sequence I side 2
(FailPh.Seq I S2)
Measurem.Superv OUT on
off
* * LED BO 135 157 1 Yes
267 Failure: RTD-Box 2 (Fail: RTD-
Box 2)
Supervision OUT ON
OFF
* * LED BO 135 209 1 Yes
272 Set Point Operating Hours (SP.
Op Hours>)
SetPoint(Stat) OUT on
off
* * LED BO 135 229 1 Yes
284 Set Point I< alarm (SP. I<) Set Points(MV) OUT * * * LED BO 135 244 1 Yes
301 Power System fault
(Pow.Sys.Flt.)
Device OUT ON
OFF
ON
OFF
* 135 231 2 Yes
302 Fault Event (Fault Event) Device OUT * ON * 135 232 2 Yes
320 Warn: Limit of Memory Data ex-
ceeded (Warn Mem. Data)
Device OUT on
off
**LEDBO
321 Warn: Limit of Memory Parameter
exceeded (Warn Mem. Para.)
Device OUT on
off
**LEDBO
322 Warn: Limit of Memory Operation
exceeded (Warn Mem. Oper.)
Device OUT on
off
**LEDBO
323 Warn: Limit of Memory New ex-
ceeded (Warn Mem. New)
Device OUT on
off
**LEDBO
361 >Failure: Feeder VT (MCB
tripped) (>FAIL:Feeder VT)
P.System Data 1 SP on
off
* * LED BI BO 150 38 1 Yes
394 >UE 3rd Harm. MIN/MAX Buffer
Reset (>UE3h MiMa Res.)
Min/Max meter SP on * * LED BI BO
396 >I1 MIN/MAX Buffer Reset (>I1
MiMaReset)
Min/Max meter SP on * * LED BI BO
399 >U1 MIN/MAX Buffer Reset (>U1
MiMa Reset)
Min/Max meter SP on * * LED BI BO
400 >P MIN/MAX Buffer Reset (>P
MiMa Reset)
Min/Max meter SP on * * LED BI BO
402 >Q MIN/MAX Buffer Reset (>Q
MiMa Reset)
Min/Max meter SP on * * LED BI BO
407 >Frq. MIN/MAX Buffer Reset
(>Frq MiMa Reset)
Min/Max meter SP on * * LED BI BO
409 >BLOCK Op Counter (>BLOCK
Op Count)
Statistics SP on
off
**LEDBIBO
501 Relay PICKUP (Relay PICKUP) P.System Data 2 OUT * ON m LED BO 150 151 2 Yes
511 Relay GENERAL TRIP command
(Relay TRIP)
P.System Data 2 OUT * ON m LED BO 150 161 2 Yes
545 Time from Pickup to drop out (PU
Time)
Device VI
546 Time from Pickup to TRIP (TRIP
Time)
Device VI
571 Fail.: Current symm. supervision
side 1 (Fail. Isym 1)
Measurem.Superv OUT on
off
* * LED BO 150 196 1 Yes
572 Fail.: Current symm. supervision
side 2 (Fail. Isym 2)
Measurem.Superv OUT on
off
* * LED BO 150 197 1 Yes
576 Primary fault current IL1 Side1
(IL1 S1:)
P.System Data 2 VI * ON
OFF
150 193 4 No
577 Primary fault current IL2 Side1
(IL2 S1:)
P.System Data 2 VI * ON
OFF
150 194 4 No
578 Primary fault current IL3 Side1
(IL3 S1:)
P.System Data 2 VI * ON
OFF
150 195 4 No
579 Primary fault current IL1 Side2
(IL1 S2:)
P.System Data 2 VI * ON
OFF
150 190 4 No
580 Primary fault current IL2 Side2
(IL2 S2:)
P.System Data 2 VI * ON
OFF
150 191 4 No
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log On/Off
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
