SIM7500_SIM7600 Series_AT Command Manual_V1.07 2017-12-25

138

AT+CPCMREG=1

AT+CPCMREG?

+CPCMREG:1

6.27 AT+CMICGAIN Adjust mic gain

Description

This command is used to adjust mic gain. If this command was used during call, it will take

immediate effect. Otherwise, it will take effect in next call.

SIM PIN References

NO Vendor

Syntax

Test Command

Responses

AT+CMICGAIN=? +CMICGAIN: (list of supported <value>s)

Read Command Responses

AT+ CMICGAIN?

+CMICGAIN: <value>

Write Command Responses

AT+CMICGAIN=<value> OK

ERROR

Defined values

<value>

Gain value from 0-8, 8 is the max. 3 is the default value. This value will be reset to default value

after Module reset.

Examples

AT+CMICGAIN=1

AT+CMICGAIN?

+CMICGAIN:1

SIMCOM CONFIDENTIAL FILE
