SIM7500_SIM7600 Series_AT Command Manual_V1.07 2017-12-25

278

AT+CTCPFIN?

+CTCPFIN:<TCP_FIN_Enable>

ERROR

Write Command

Responses

AT+CTCPFIN=<TCP_FIN_

Enable>

ERROR

Defined values

< TCP_FIN_Enable >

a numeric parameter which sets whether waiting for TCP_FIN inTCP_FINWAIT2 state.

0 not waiting

1 waiting

Examples

AT+CTCPFIN=?

+CTCPFIN: (0,1)

AT+CTCPFIN=1

15.1.8 AT+CTCPKA Conigure TCP heartbeat

Description

This command is used to set TCP heartbeat parameters..

SIM PIN References

YES Vendor

Syntax

Test Command

Responses

AT+CTCPKA=? +CTCPKA: (list of supported <TCP_KA_Enable>

s),(list of

supported <KeepIdleTm>

s) ,(list of supported

<KeepAliveMaxTry>s)

Read Command Responses

AT+CTCPKA?

+CTCPKA:<TCP_KA_Enable>,<KeepIdleTm>,<KeepAliveMaxT

ry>

SIMCOM CONFIDENTIAL FILE
