SIM7500_SIM7600 Series_AT Command Manual_V1.07 2017-12-25

281

AT+CUPURE=<UDP_POR

T_UNREACHABLE_Enabl

ERROR

Defined values

<UDP_PORT_UNREACHABLE_Enable>

a numeric parameter which

sets whether enable or disable UDP port unreachable ICMP echo

option.

0 disable

1 enable

Examples

AT+CUPURE=?

+CUPURE: (0,1)

AT+CUPURE=1

15.1.11 AT+CINICMPALLOW Preferred ICMP filter

Description

This command is used to filter the incoming ICMP packets that are not allowed.

SIM PIN References

YES Vendor

Syntax

Test Command

Responses

AT+ C INICMPALLOW=?

+ CINICMPALLOW: (list of supported <mode>s)

ERROR

Read Command Responses

AT+ C INICMPALLOW?

+CINICMPALLOW: <mode>

ERROR

Write Command Responses

AT+CINICMPALLOW=<m

ode>

ERROR
