SIM7500_SIM7600 Series_AT Command Manual_V1.07 2017-12-25

280

ERROR

Write Command Responses

AT+CTEUTP=<Echo_Unkn

own_TCP_Enable>

ERROR

Defined values

<Echo_Unknown_TCP_Enable>

a numeric parameter which sets whether enable or disable unknown incoming TCP packet echo

option.

0 disable

1 enable

Examples

AT+CTEUTP=?

+CTEUTP: (0,1)

AT+CTEUTP=1

15.1.10 AT+CUPURE Set UDP port unreachable ICMP echo

Description

This command is used to enable or disable UDP port unreachable echo.

SIM PIN References

YES Vendor

Syntax

Test Command Responses

AT+CUPURE=? +CUPURE:

(list of supported

<UDP_PORT_UNREACHABLE_Enable>s)

ERROR

Read Command Responses

AT+CUPURE? +CUPURE:< UDP_PORT_UNREACHABLE_Enable>

ERROR

Write Command Responses

SIMCOM CONFIDENTIAL FILE
