SIM7500_SIM7600 Series_AT Command Manual_V1.07 2017-12-25

246

12 AT Commands for Hardware

12.1 AT+IPREX Set local baud rate permanently

Description

This command sets the baud rate of module’s serial interface permanently, after reboot the baud rate

is also valid, if set to 0, then support autobaud, and t

he value of the IPR will be changed to current

baudrate when the autobaud is successful.

SIM PIN References

NO Vendor

Syntax

Test Command Responses

AT+IPREX=?

+IPREX: (list of supported<speed>s)

Read Command Responses

AT+IPREX?

+IPREX: <speed>

Write Command Responses

AT+IPREX=<speed> OK

ERROR

Execution Command Responses

AT+IPREX Set default value 115200:

Defined values

<speed>

Baud rate per second:

0, 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400, 460800, 921600,

3000000, 3200000, 3686400

Examples

AT+IPREX?

+IPREX: 115200

AT+IPREX=?
