12.6 AT+CGDRT Set the direction of specified GPIO

Description

This command is used to set the specified GPIO to input or output state. If setting to input state,

then this GPIO can not be set to high or low value.

SIM PIN References

NO Vendor

Syntax

Test Command

Responses

AT+CGDRT=? +CGDRT: (list of supported <GPIO>s),(list of supported <

gpio_io >s)

Write Command Responses

AT+CGDRT=<GPIO>,

<gpio_io>

ERROR

Read Command Responses

AT+ CGDRT=<GPIO> + CGDRT: <GPIO>,<gpio_io>

ERROR

Defined values

<GPIO>

The value is GPIO ID, different hardware versions have different values.

<gpio_io>

0 – in

1 – out

Examples

AT+CGDRT=43,0
